Fit 32 independent waveform channels into one PXI slot
PRODUCT FEATURES
- +/-25 V output range with 16-bit resolution
- DC to 50 kHz, full amplitude
- 50 kHz to 300 kHz, reduced amplitude
- 8, 16, 24 or 32 channels in single 3 U Slot
- 5.76 mHz frequency resolution
RELATED PRODUCTS
PRODUCT INFORMATION
MANUFACTURED BY Pickering
PUBLISH DATE
September 2, 2026
RELEASE DATE
June 23, 2026
MODEL/SERIES
41-625 PXI and 43-625 PXIe
CATEGORY
Data Acquisition, DAQ
Pickering 41-625 PXI and Pickering 43-625 PXIe multi-channel waveform generators offer up to 32 independently controlled output channels within one3U PXI/PXIe slot. The modules generate waveforms from DC to 300 kHz for applications such as accelerometer simulation and other systems requiring multiple stimulus signals. Each channel has dedicated memory for sine waves, standard waveforms and user-defined arbitrary waveforms. Software-controlled frequency adjustment uses Direct Digital Synthesis. Trigger functions enable external instruments to initiate waveform generation or frequency sweeps.
Courtesy: TREW Marketing
Pickering
