Can there be a single wireless protocol for field devices?

One fieldbus protocol has emerged as the leading solution for process applications, and our industries have benefitted. Perhaps the same thing can happen with wireless field devices.


Figure 1: Multiple field temperature transmitters in a refinery application can handle more than one probe. Courtesy: YokogawaProcess industries do not adopt new technologies instantaneously. On the contrary, they normally begin gradually and methodically with applications where that technology provides enough benefits to overcome the risk that it will not work at all or will not work reliably. Many users will test the new technology on a few pilot installations, usually for noncritical processes. With operational success and sufficient economic incentive, the new technology will be specified for new plant construction in locations where vendor support is available. Eventually the new technology will be specified for greenfield plant construction, major revamps, and modernization projects, ultimately becoming an industry norm. Foundation fieldbus (FF) has followed this pattern with the basic technology becoming a standard in 1996, and now almost 20 years later, it is the industry norm for new plant construction and modernization in continuous flow process industries such as petroleum refining, petrochemicals, and chemical manufacturing.

Like wired process control communications standards in 2000, today there are directly competing standards for wireless field instrumentation: IEC 62734 (ISA100.11a) and IEC 62591 (WirelessHART.) These two standards appear to be very similar because they are both based on the same IEEE 802.15.4 radio chip, but they are actually quite different and not interoperable. WirelessHART was designed by the HART Communications Foundation specifically to transport HART data over a wireless network as simply as possible, and to be installed and managed with the familiar HART tools and methods. ISA100 wireless was designed by an open standards organization with technical experts from more than 250 countries to be a wireless Internet-based telecommunications protocol for process control data now and for future applications not yet invented. It was designed for efficient transportation of HART and practically any fieldbus data objects that use standard IEC 61804 (EDDL).

Following the fieldbus example

One of the problems that is delaying broader acceptance of wireless field instrumentation is that most new plant installations and major modernization projects are now using Foundation fieldbus, a wired all-digital network of very intelligent field instruments. A wireless equivalent or version of FF H1 is not yet available, although both WirelessHART and ISA100 wireless networks can exchange simple data from either wireless network through a ROM (Remote Operations Manager), a Fieldbus Foundation-specified gateway. However, lack of a true wireless version of FF with the same intelligent but wireless field instruments is not available. Not yet tested by the Fieldbus Foundation is FF HSE (high-speed Ethernet) working on Wi-Fi, or this same HSE protocol working on an ISA100 wireless IP-based network. There is no wireless version of FF HSE linking device offered or registered by any vendor.

Users are very concerned that there are effectively two competing wireless network standards being supported by the major instrument companies. Of even greater concern is that often the wireless network standard used by their favorite field instrument supplier is not compatible with the wireless network standard support by their favorite DCS supplier. Users look to their suppliers to solve such problems; vendors must bring solutions to their customers-not problems. Lack of a single wireless network norm, or generally accepted industry practice, has hampered user acceptance of wireless field instrumentation except in a few areas where the benefits of wireless are overwhelming, and applications are not for fast control loops.

Comparing ISA100 to WirelessHART

What are the features of ISA100 that make it the better choice as a wireless network for a new process control applications? As the HART Communication Foundation says in its description of the platform, "WirelessHART technology allows users to access the vast amount of unused information stranded in these installed HART smart devices."

ISA100 was designed explicitly for communications with smart process control field instrumentation, and for easy configuration to a specific set of high-performance requirements. There are many configurable choices possible in the preparation of an ISA100 wireless device that are specified in the standard. The set of default values for these choices, which appears in the standard, is called the router profile, which has been optimized for secure mesh networking of process control field instrumentation.

Therefore, users of wireless process control field instrumentation do not need to configure new wireless instrumentation to meet any of the options of this standard. Manufacturers of other wireless devices may have specific cost, performance, or security needs which may use the I/O profile also specified in the standard for low-cost devices, or may require adjustments to some other ISA100 attributes to customize it to their needs. Customized versions of ISA100 are guaranteed and compliance tested to interoperate with field instruments conforming to the router profile, but adjustment of the ISA100 wireless profile is not something that users need to worry about.

During the design of ISA100, the same basic set of requirements was used that was used many years before during the design of FF. Essential to the architecture of both ISA100 and FF is peer-to-peer transfer of data without requiring a host or gateway relay. Both ISA100 and FF devices have a synchronized real-time clock to support the scheduling of objects resident in intelligent network devices. ISA100 devices have a synchronized real-time clock accurate to ± 1.0 ms. This clock precision is also necessary to support an electric power utility industry user requirement for post-mortem trip sequence analysis.

For example, most process control field instrumentation sampled once per second (1 Hz) is adequate for monitoring and most closed-loop control. ISA100 can deliver this data to a DCS doing such control with time synchronous accuracy. WirelessHART has no time synchronization capability. When flow control requiring updates faster than once per second is to be configured, only ISA100 can deliver data with a synchronous response more often than once per second. Typical distillation column flow control requires data to be scanned two to four times per second. To deliver this type of performance, the data collection times for the flow transmitters should be configured with minimal network meshing to guarantee synchronous sample times. ISA100 explicitly supports a maximum latency of 100 ms and the field backhaul routers necessary to enable data to reach the controller in a single hop without the non-deterministic delays of a mesh network.

When applications are even more demanding than 4 Hz flow control, it may become necessary for the user to configure the ISA100 data-link layer to allow processing up to 12 Hz, which is the current design limit. The advantage of ISA100 is that the user has this option available without needing to change the protocol, or to create new function blocks that are not supported by Fieldbus Foundation interoperability testing.

Provision for complex devices

Applications such as analytical field instrumentation may require transmission of long data sets that cannot fit into short messages necessary with a 10 ms slot time. The network segment that includes the wireless analyzers may use the ISA100 features to allow longer messages. The application can segment the message such that the data payload is less than about 90 bytes, allowing for the protocol overhead. ISA100 supports reassembly of segmented long messages. WirelessHART with its fixed 10 ms slot time and simplistic network layer is not suitable for efficient transfer of long messages, and the responsibility to segment and reassemble messages is left to the application. The issue of leaving it outside the standard and conformance testing is that it will make it more difficult, if not impossible, for multiple manufacturers to develop interoperable products.

One of the features unique to ISA100 is tunneling, which gives the ability to transport any data stream across the ISA100 wireless network, between a field device and the gateway even if the device uses a digital protocol quite different from ISA100. As a preferred alternative approach, the object-oriented ISA100 application layer has enabled wireless adapters to form simple valid messages using the ISA100 object model and services. The device may have ISA100 built-in or an adapter may be mounted on the device to receive and transmit messages in the native format of the device such as Modbus, DeviceNet, ControlNet, EtherNet/IP, Profibus, HART, etc., and encapsulate the message for transport over the ISA100 wireless network to the gateway.

Most applications have used the ISA100 object model to pass data previously expressed in the native protocols mentioned, and have not needed to use the tunneling features. Software in the gateway can then route the data contained in the original message to an intended receiver. Since the ISA100 adapter has an IP address, external systems may route messages to the field device at that IP address much as they can interact with any other IP device.

One of the future applications for ISA100 is to serve as the field network connection for devices hosting web pages. While there are currently no web page hosting applications for field devices, the ISA100 infrastructure enables such applications. Similarly, a smart device may run the protocol of FF HSE, which is also UDP/IP-based, and the ISA100 wireless network will be able to synchronously exchange messages and data with any other device running that same protocol using the publish/subscribe features of ISA100 that are compatible with those of FF.
