Question 1

How does a DAQ device work?

Accepted Answer

A data acquisition (DAQ) system converts analog signals from sensors and other devices into digital signals that can be read and processed by a computer. It typically includes sensors, signal conditioning, an analog-to-digital converter (ADC), and a computer interface to read the converted data. DAQ systems are used to collect and analyze data in real-time and are used in a variety of applications such as scientific research, industrial automation and control systems.

Question 2

Is DAQ a controller?

Accepted Answer

A data acquisition (DAQ) system is not a controller. A DAQ system is used to collect and digitize data from various sensors and sources, but it does not control the process or actuate using the data collected.

A controller on the other hand, uses the input data and makes decisions based on that data, and sends output commands to actuators to control the process. It is a device or system that manages, commands, directs or regulates the behavior of other devices or systems.

However, DAQ systems are often used in conjunction with controllers, where the DAQ system provides real-time data to a controller, which uses the data to make decisions and control the process. DAQ systems act as a data input source for the controllers, and the controllers actuate on the data to control the process.

Question 3

What is an example of data acquisition?

Accepted Answer

An example of data acquisition (DAQ) is monitoring the temperature of an industrial oven during the manufacturing process. Temperature sensors are placed inside the oven, and the sensors are connected to a DAQ system. The DAQ system converts the analog signals from the temperature sensors into digital signals, which are then sent to a computer. The computer can then display the temperature data in real-time, and also store the data for later analysis.

Question 4

What are the main components of DAQ system?

Accepted Answer

A data acquisition (DAQ) system typically includes the following components:

Sensors: These are devices that convert physical phenomena such as temperature, pressure or flow into electrical signals that can be read by the DAQ system.
Signal conditioning: This is the process of cleaning analog or digital inputs for transfer and may prepare sensor signals for conversion to digital form. This may include amplifying, filtering or isolating the sensor signals to ensure they are accurate and within the appropriate range for an analog-to-analog or analog-to-digital converter.
Analog-to-digital converter (ADC): This is the component that converts the analog signals from the sensors into digital signals that can be read and processed by a computer.
Computer interface: This is the connection between the DAQ system and the computer, which allows the computer to read the digital data and also to send commands to the DAQ system.
Software: DAQ systems often come with software that allows the user to configure the system, read data and analyze the data.
Cabling and connectors: DAQ systems usually require cabling and connectors to interconnect the different components and to connect to the sensors and actuators.
Power supply: DAQ systems require power supply to operate and convert the signals.
