The Turck Q130 HF read/write head reads and writes data to RFID tags on moving products and carriers. It can be used in automatic identification and tracking applications that require a single read point. It supports applications such as conveyor transport, overhead cranes, autonomous mobile robots (AMRs) tote tracking and material handling in packaging plants and warehouses. Its extended temperature range of -40 to +70 °C makes it suitable for cold storage logistics.
The Q130 HF read/write head can read and write data carriers while in motion, supporting high conveyor throughput rates.
This device integrates the interface block, which can help reduce hardware requirements and simplify installation. Its multiprotocol interface supports communication over Profinet (PI North America), EtherNet/IP (ODVA) and Modbus TCP networks. Integrated S2 system redundancy allows communication between two controllers, improving system reliability and uptime. Turck Q130 HF feature summary:
- Integrated read/write head with built-in Ethernet interface, removing the need for separate block I/O and additional cabling
- Designed to maintain accuracy in higher speed applications
- Extended temperature range of -40 to +70 °C, for use in cold storage
- Multiprotocol support (EtherNet/IP, Profinet and Modbus TCP)
- High IP rating: IP69K front, IP67 rear, ensures a reliable solution in tough applications.
Edited by Puja Mitra, WTWH Media, for Control Engineering, from a Turck news release.
