NR60E2 Ethernet absolute rotary shaft encoder

June 27, 2023

The AMCI NR60E2 series of heavy-duty Ethernet Encoders are compatible with all PLCs/PACs that support EtherNet/IP, Modbus-TCP or Profinet. The NR60E2 series Ethernet encoders are available in absolute single-turn and multi-turn packages using an IP67 rated 60mm diameter industrial housing. Flange and servo mounting styles are available to suit various mounting requirements. These networked absolute rotary encoders provide up to 30 bit total resolution, delivering 16 bit (65536 steps) per revolution and up to an additional 14 bit (16384 revolutions) for multi-turn versions.

AMCI’s Ethernet encoders are designed for simple set-up and trouble free performance. The NR60E2 Ethernet encoders are compatible with all PLCs and PACs that support EtherNet/IP, Modbus-TCP, or Profinet including Allen-Bradley, IDEC, Siemens, and Schneider. Programmed using the PLC/PAC resident software ensures hassle free integration with your application.

The NR60E2 Ethernet encoders offer a variety of programmable features:

  • Selectable Resolution

  • Selectable Count Direction

  • Selectable Velocity Format

  • Programmable Presets for Zeroing or Homing

All programmable parameters and the preset offset are stored in the internal non-volatile memory for speedy retrieval, making it quick and easy to configure your NR60E2 Ethernet encoder.
